A long-format sensor breakout with a row of pin headers and crystal-locked timing.
Sensor breakout board with a 16-pin right-side male header for ribbon-cable attach to a host. Shielded ESP module, USB-C for programming, big through-hole capacitor for ripple suppression, and a careful trace plan for low-noise analog routing. Built for a multi-channel sensor array data-logger.
